Install AWX on K3S

Since version 18, AWX, the comunity edition of ansible tower gets deployed by a kubernetes operator.
This makes it easier to install and maintain the installation, but not all of us are familiar with kubernetes and operators.
So I share a short step by step guide on how to setup ansible awx in a "semi professional" way on a single k3s kubernetes node.

1 VM Setup

1.1 VM requirements

Just setup a CentOS8 minimal VM with the following requirements

• OS: centos8 minimal

• CPU: 2
• MEM: 8GB (6 GB may work as well)
• DISK: 40G (7GB used on a fresh setup)

1.2 Prepare OS

dnf -y upgrade
dnf -y install setroubleshoot-server curl lsof wget

sed -i  '/swap/d' /etc/fstab
swapoff -a

firewall-cmd --permanent --zone=public --add-service=https
firewall-cmd --zone=public --add-masquerade --permanent
firewall-cmd --reload
reboot

2 Setup K3S

curl -sfL https://get.k3s.io | sh

cat /etc/systemd/system/k3s.service
systemctl status k3s

kubectl get nodes
# all pods in running state? fine!
kubectl get pods --all-namespaces

# install kustomize
cd /usr/local/sbin/
curl -s "https://raw.githubusercontent.com/kubernetes-sigs/kustomize/master/hack/install_kustomize.sh"  | bash

3 Deploy AWX

export NAMESPACE=awx
kubectl create namespace $NAMESPACE
kubectl config set-context --namespace=$NAMESPACE --current

cd ; mkdir git ; cd git
git clone https://github.com/ansible/awx-operator.git -b 0.16.0
cd awx-operator/
make deploy
	# cd ~/git/awx-operator/config/manager && /usr/local/sbin/kustomize edit set image controller=quay.io/ansible/awx-operator:0.16.0
	# cd ~/git/awx-operator && /usr/local/sbin/kustomize build config/default | kubectl apply -f -

kubectl get pods -n $NAMESPACE
	NAME                                               READY   STATUS    RESTARTS   AGE
	awx-operator-controller-manager-6795f9f5f5-xq4nt   2/2     Running   0          6m1s

cd ~/git/
vim awx-instance.yml
------
---
apiVersion: awx.ansible.com/v1beta1
kind: AWX
metadata:
  name: awx
spec:
  ingress_type: Ingress
  route_tls_termination_mechanism: edge
  hostname: tower.domain.com
------

kubectl apply -f awx-instance.yml

kubectl get all
kubectl logs -f deployment.apps/awx-operator-controller-manager -c awx-manager
kubectl get events -w

kubectl get deployment
	NAME                              READY   UP-TO-DATE   AVAILABLE   AGE
	awx-operator-controller-manager   1/1     1            1           30m
	awx                               1/1     1            1           19m

kubectl get ingress
	NAME          CLASS    HOSTS         ADDRESS        PORTS   AGE
	awx-ingress   <none>   tower.domain.com   10.112.8.203   80      19m

kubectl get svc
	NAME                                              TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)    AGE
	awx-operator-controller-manager-metrics-service   ClusterIP   10.43.225.102   <none>        8443/TCP   33m
	awx-postgres                                      ClusterIP   None            <none>        5432/TCP   23m
	awx-service                                       ClusterIP   10.43.155.232   <none>        80/TCP     22m

4 Fetch the secret and test the login

kubectl get secret awx-admin-password -o jsonpath='{.data.password}' | base64 --decode

firefox https://fqdn.domain.com

• user: admin

5 Links

• https://rancher.com/docs/k3s/latest/en/quick-start/
• https://rancher.com/docs/k3s/latest/en/backup-restore/
• https://github.com/ansible/awx-operator

6 Debug Notes

6.1 Open Node Port for direct access

PORT=$(kubectl describe svc awx-service | grep NodePort: | awk '{print $3}' | tr 'A-Z' 'a-z')
echo PORT=$PORT
firewall-cmd --zone=public --add-port=$PORT

6.2 Disable SELinux

setenforce 0
> /var/log/audit/audit.log
# do some bad things
sealert -a /var/log/audit/audit.log

6.3 Traefik Config

- https://levelup.gitconnected.com/a-guide-to-k3s-ingress-using-traefik-with-nodeport-6eb29add0b4b

kubectl -n kube-system edit cm traefik

6.4 Jump into container for debugging

# get pods
kubectl get pods
# get containers inside of pods
kubectl describe <pod-name>

kubectl exec --stdin --tty <pod-name> -c <container-name> -- /bin/bash

7 Notes

7.1 Backup Restore

• Remind, Creds get not exported

pip install ansible-tower-cli

awx-cli config host http://<new-awx-host.example.com>
awx-cli login admin

awx-cli user list # If the test is successful, the user will be displayed

# export
awx-cli receive --all > assets.json

# import
awx-cli send assets.json

7.2 Pull Galaxy deps in projects by requirement files

• https://github.com/ansible/awx/issues/8765
